Temperature Sensor Probe For Air Fryer

This series of temperature sensors use high thermal conductivity thermal paste, which can design various stainless steel tubes according to the customer's structure. The appearance of various stainless steel tubes can be customized according to the temperature measurement speed requirements, and various characteristic parameters can be customized or matched according to customer needs. , IPX3 to IPX7 grades can be customized according to customer needs. This series of products have stable and reliable performance and high-temperature measurement sensitivity.

Contact us
Inquiry Basket
OEM:
Available
Sample:
Available
Payment:
PayPal,Western Union,T/T
Place of Origin:
China
Supply Ability:
140000 pcs per Day
Temperature Sensor Probe For Air Fryer

High thermal conductivity thermal paste is used in this series of temperature sensors, which may construct different stainless steel tubes based on the customer's structure. According to the requirements for temperature measurement speed, different stainless steel tubes' appearances can be adjusted, and different characteristic parameters can be matched or adjusted to suit the demands of the client. IPX3 to IPX7 grades can be adjusted to suit the needs of the customer. High-temperature measurement sensitivity and steady and reliable performance are features of this product line.



The Features of Temperature Sensor Probe For Air Fryer

  • Size can be customized
  • Personalized appearance can be designed according to needs
  • High temperature measurement sensitivity
  • The resistance value and B value have high precision, good consistency, and stable performance.
  • High temperature resistance, wide application range.
  • Food grade 304 stainless steel, food grade silicone wire.



The Characteristic Parameters of Temperature Sensor Probe For Air Fryer

Resistance R25℃=231.5KΩ±1% B100/200℃=4537K±2%
Working Temperature Range -50℃~+230℃
Thermal Time Constant MAX.6sec
Wire 380℃ stainless steel mesh braided PTFE wire
Plug 2.5mm or 3.5mm
Support OEM, ODM order



The Working Principle of Temperature Sensor Probe For Air Fryer

The air fryer has a top oven device, which is used to set the heating time and temperature adjustment. The temperature adjustment depends on the NTC temperature sensor part (its resistance value will decrease as the temperature increases.). The temperature used in the air fryer is relatively high, so the temperature control must be very well controlled. Once the temperature exceeds the set value, it will automatically cut off the power; to avoid accidents. The temperature of the air fryer is well controlled, and its surface will become crispy and golden, which will achieve the texture and appearance of frying.



The Application of Temperature Sensor Probe For Air Fryer

Baked oven, grill, air fryer
